25000 Lux Safety Underground Mining Cap Lamp with Cable Flashlight
Quick Detail
GS12-A uses 1pc Cree led as main light,2pcs SMD leds as the
auxiliary lights,and designed with high capacity 6.8Ah rechargeable
panasonic Li-ion battery. It has three levels power as
High-15000lux, Mid-10000lux , Flashlight.
This new cap lamp uses Li-ion batteries which can keep the lamp
more than 13 hours continuous working time. The motherboard is
designed with short-circuit, over-charging, over-discharging
protection. And it is also high temperature and low temperature
resistant. It is also waterproof, anti-explosive, compact
resistant, fire retardant to keep safety use.
Main Features
1. Support portable USB charging.
2. Four lighting modes : weak-strong-auxiliary -SOS
3. Design with excellent weight balance on helmet.
4. High brightness 15000lux high beam corded lamp
5.More than 15hrs working time.
6. Safety rope for lamp falling down searching.
7. 6.8Ah big capacity ,panasonic battery pack.
8.392g light weight
9.Rear warning light with red,green,blue three colors for
options.This function can make your worker more safe.It also can
indicate the charging status.
10.Explosive proof, flame-resistant,impact-resistant,IP 68
water-proof.
11.Low power warning function for safety lighting.
12. Aluminum lighting cup with better lighting spot.
Main parameter of rechargeable led headlamp
| Specification | GL12-A | GLC12-A | GLS12-A |
| Light sources | One main light and two auxiliary lights | One main light and two auxiliary lights | One main light and two auxiliary lights |
| Rated voltage | 3.7V | 3.7V | 3.7V |
| Battery capacity | 10.4Ah | 10.4Ah | 6.8Ah |
| Main light current(strong light) | 850mA | 850mA | 450mA |
| Main light current (working light) | 450mA | 450mA | 450mA |
| Power of the main light(strong light) | 3W | 3W | 1.7W |
| Power of the main light(working light) | 1.8W | 1.8W | 1.7W |
| luminous(strong light) | 348Lum | 348Lum | 221Lum |
| luminous(working light) | 240Lum | 240Lum | |
| Brightness of the main light(strong light) | 25,000Lux | 25000Lux | 15000Lux |
| Brightness of the main light(work light) | 15,000Lux | 15000Lux | |
| LED lifespan | 10,000hours | 10,000hours | 10,000hours |
| Battery cycles | 1200cycles | 1200cycles | 1200cycles |
| Working time | 13-15hours | 13-15hours | 13-15hours |
| Cable length | 1.2m or 1.6m can be customized | 1.2m or 1.6m can be customized | 31CM/customized |
| Weight | 450g | 456g | 392g |
| Water-proof grade | IP68 | IP68 | IP68 |
| Light switch | Microswitch | Push button | Push Button |
| Certified | CE&ATEX, ROHS | CE&ATEX, ROHS | CE&ATEX, ROHS |
SOS
Hold the button for 3 seconds
GLC12-A's SOS mode will be opened. 3 quick flashes and 3 slow flashes - telling others that there are people here who need help.
Product image
Application
Our products can be widely used for camping, travelling,
cycling,tool, maintenance lighting,fishery, diving, fire-fighting
,military, architecture, living,furniture, farm lighting,night
fishing, car-carrying, road and railway lighting, forest farm.
Manufacturing and Equipment
Our factory covers an area of 5,000 square meters and provides good
working environment for our employee. We have the complete set of
equipment, perfect production and quality management system. We
manufacture our products by high standard and strict quality
control and we fully follow out ISO quality management system
standard.
