Corded LED Mining Cap Lights with USB Charging Safety Back Up Light
18 Hours Work Time
Details of GL8-D miners cap lamp:
1. Yellow/green bezel for your options. (Yellow color is more popular).
2. USB cable + Traditional Cradle Charger
3. High Low Beam : Main Light (10000Lux) + Auxiliary Light (back up light for
emergency).
4. Low Power Warning Function for your options(this fuction can remind you to charge,
when lower voltage, the main light turns automatically to auxiliary
light)
5. SOS mode will be opened. 3 quick flashes and 3 slow flashes - telling
others that there are people here who need help.
6. Package: 1pcs headlamp, 1pcs charger/USB cable, package box,
manual
Advantages for Model GL8-D mining headlights with cable:
- With low power warning function for safety lighting.
- American CREE LED as main light source, and 2 pcs back up light.
- full brightness with lighgting working up to18hours; 10000lux.
- aluminun charger with MCU controlled system.
- CE/Exi approved.
- Silicon button cap with with good touch.
- Excellent apperance and good processing.
- All of our lamps has one year warranty. We will keep free
maintenance if any quliity problem for you in one year.
- We are still responsible for you after cooperation between us.
- Support USB charging.
- Have charging indication led. (Red -on charging; green - full
charging).
Spare Parts available
Bezel Ring + Glass and Gasket + LED, Reflector and PCB + Housing
and Ring + Steel Clip and Screws + 6.6Ah Li-ION Battery Pack +
Battery Case with 1.65M cable - Complete + Security Tool +
Traditional desktop cap lamp charger + USB charging cable
Main parameter of two series of rechargeable headlamp:
| Items | Value | Value |
| Model | GL8-D | GL5-D |
| Light Source | 1 main light and 2 auxiliary lights | 1 main light and 2 auxiliary lights |
| Battery Capacity | 7.8Ah Li-ion battery pack | 6.6Ah Li-ion battery pack |
| Rated Voltage | 3.7V | 3.7V |
| Main light current | 450mA | 450mA |
| Power of main light | 1.67W | 1.67W |
| Illuminous | 216lum | 216lum |
| Brightness | 10000lux | 10000lux |
| Life span of main light | 100000hours | 100000lux |
| Battery cycles | 1000cycles | 1000cycles |
| Working time | 18hours | 16hours |
| Weight | 420g | 420g |
| Waterproof grade | IP68 | IP68 |
Charging picture shown:
- Support USB charing
- Traditional cradle charger
Good Appearance:
Safety warnings :
1. Shooting at eyes directly must be avoided while the lamp is
working since the light is so bright and can hurt eyes.
2. Disassempling the cap lamp into parts is not permitted,since it
is not safe an dreliable to work underground without the full
suitable components.
3. Forbidden to crash and strike the lamp.
4. Not allowed to charge the lamp underground.
5. Keep the lamp away from fire sources.
6. Do not disassemble the lamp or change the part underground,All
the maintenance and repair must be done on the surface! It is not
allowed to replace the done on the surface! It is not allowed to
replace the structure of the cap lamp and the parts.
7. D o not disassemble the lamp or repair the battery parts by
yourself.
8. The discarded cap lamp should be disposed together rather than
throw away without management.
Use scope
Coal mining, marine using, exploration working, underground tunnels
Emergency rescue: firefighting, flood prevention, tapping rubber,
Outdoor advanture: fishing, hunting, camping, auto repair and other
related industries.
It is also suitable for industrial and agricultural production and
outdoor mobile lighting.
Green Lighting Electronics Co.,LTD.
High safety cap lamp with tracking systems is trend for underground
mines/tunnel sites.
We are researching and developing tracking systems to plant into
cap lamp.
Simple NFC tags design into caplamp to manage miners work
attendance.
RFID TAG to store data about mine lamp info.
We trust we can make it successfully in the near future.
Our aim: offering good quality high safey cap lamp for underground miners.
Our clients: we are proud to be OEM factory for our Canada Customer and South
African Customers (Big company for selling mining cap lamp with
tracking systems)
Our service: 1year warranty time if any quality problem.
Our pursuit: Customer's satisfaction and good usage feedback.
Hope sincerely cooperate with you and grow up together (business or
lamp technology).
