USB Charging IP68 Anti-explosive Underground Safety Wireless Coal
Mining Headlamp With OLED Screen
Quick detail
GLC-6S Mining Cap Lamp is Green Light Latest cordless cap lamp.New
generation-Update generation on the basis of GLC-6 according to cusomers
feedback. Uses CREE 3W high power white led as main light, 2pcs SMD LEDs as
the auxiliary lights, and designed with high capacity 6.8Ah
rechargeable Li-ion battery.
With the specially designed reflector maximum is 25000lux. Lighting
time is more than 18 hours, 4 hours charging time with USB.OLED Display the battery status, time, date and client's company
information.
Specifications
| Model | GLC-6S Cordless cap lamp |
| Light source | one main light two auxiliary lights |
| Battery Capacity | 6.8Ah |
| Rated Voltage | 3.7v |
| Main light current | 400mA-530mA-1000mA |
| Power of main light | 4.2W |
| Illuminous | 232lum |
| Brightness | 9000lux-14000lux-18000lux |
| Life span of main light | 100000hrs |
| Battery cycles | 1200 cycles |
| Working time | 17hrs-13hrs-6hrs |
| Weight | 245g |
| Water-proof grade | IP68 |
Main features of GLC-6S Cordless cap lamp
1)Rated Capacity:5Ah Rated Voltage:3.7V.
2)Begin lighting:>13000Lx Lighting 11h:>8000Lx
3)Battery life:>1200times
a) Small,Light weight,Easy to carry and energy efficient,Equipped
with specially designed optical system,with primary and secondary
pairs of light. When one light source is damaged, the other source
can ensure the work in mine and safe evacuation.
b) The produce is portable, made of lamp holder, cable and battery
(including lithium battery, security device and the battery slot,
etc.). The lamp is equipped with two light sources, and it can be
fixed on mine helmet. The case is made of Bullet-proof ABS
Material. Excellent toughness, Anti-static, waterproof, and
moisture-proof, the miner's safety is highly improved.
c) The mine’s lamp is maintenance-free, no need to replace the
light source and add additional acid for the battery. The battery
has over-voltage, over-current, over-discharge, over-temperature
protection, short circuit protection and other automatic protection
function, and use of safe, reliable. The life of LED is long.
Product Pictures:
Technical parameters
NO. | item | parameter | unit | remark |
1 | Rating voltage | 3.7 | V | |
2 | Rating capability | 5 | Ah | |
3 | Lighting duration(main lamp-house) | ≥20 | H | The real duration is more |
4 | intensity of illumination(main lamp-house) | beginning | ≥8000 | Lux | 1 meter from the lamp |
| | After 11 hours | ≥5000 | | |
5 | LED average current | main lamp-house | 350 | MA | |
| | secondary lamp-house | 160 | | |
6 | Charge protective voltage | 4.8 | V | |
7 | Discharge protective voltage | 3.0 | V | |
8 | Battery circular life | >1000 | CIRCLE | Circular times |
9 | Weight | 200 | g | |
Application
This cap lamp can be used in Mine, underground working, Patrolling,
Overhauling and Emergency in an electrical power company, Military,
Police, Fire Fighting, Dockyard, and other hazardous locations,
etc.
Packing
one set each gift box with 1pcs lamp + 1pcs USB +1pcs Wall charger
+ 1pcs Manual 30 sets/ carton
FAQ
Q: 1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. We can
offer you sample to test for free and you pay the delivery cost.
Q: 2. What is the lead time?
A:Sample needs 5-7days, mass production time needs15-20 days.
Q: 3. How to proceed the order when customer order products?
A: Inquiry-Confirmation-Send Proforma Invoice-Customer make
payment-Arrange production-ship the goods to
customers-Confirmation-Finish.
Q: 4. How to make this payment?
A: L/C,TT, Paypal, Western Union.
Q: 5. Do you offer guarantee for the products?
A: Yes, we offer one year guarantee for the products.
Q: 6. Do you accept OEM/ODM?
A: Yes, it’s available.ODM / OEM can be accepted and logo can be
customized according to your requirement.
