High Intensity Cordless Safety LED Mining Lights with Lightweight
Engineering PC Shell
Features of Model GLC-6 led mining light:
1. OLED screen: display time, battery capacity, date.
Advantage: Safety lighting usage: you can charge your miner light
when power nearly run out.
2. USB charger/Cradle Charger up to your options and magnetic connecting charging spot.
Advantage: Convenient. You can charge it on the car, computer,power
bank.
3. All in one stuture.
Advantage: perfect waterproof IP68.
4. 2A charger.
Advantage: fast charging.
5. Size: 85*72*58mm. 160-210g weight.
Advantage: Portable.
6. Superior brightness: 4000-13000LUX is supplied up to your
options.
7. SOS lighting mode.
Advantage: safe working in emergency.
8. Auxiliary light:
Advantage: when lower power, you can use AL to get more working
lighting time.
9. Detachable structure
Advantage: repair or replace inside parts is available,bring you
'use again'.
10. Special material
Advantage: flame retardant material with anti-exolosive, flame-resistant, impact-resistant.
11. Adjustable stainless steel clip to change lighting angle.
12. Lighting levels: Main light - auxiliary light - SOS three
lighting modes.
13. Lithium Battery
Advantage: electrical short circuit protection, over-charging and
over-discharging protection.
14. Push Button.
Easy and confortable to turn off/on miner lights, time setting.
15. High/low light mode.
Main parameter of GLC-6 Series:
| Item | GLC-6(A) | GLC-6(B) | GLC-6(C) | GLC-6(D) | GLC-6(E) |
| Light Source | one main light and
two auxiliary lights | one main light and
two auxiliary lights | one main light and
two auxiliary lights | one main light and
two auxiliary lights | one main light and
two auxiliary lights |
| Battery Capacity | 5.2Ah | 6.8Ah | 2.6Ah | 3.4Ah | 5.2Ah |
| Rated Voltage | 3.7V | 3.7V | 3.7V | 3.7V | 3.7V |
| Power of the main light | 1.67W | 1.78W | 1.3W | 1.3W | 1.3W |
| Illuminous of the main light | 167Lum | 232Lum | 130Lum | 130Lum | 130Lum |
| Brightness of the main light | 10000lux | 13000lux | 4000lux | 6000lux | 10000-12000lux |
| Oled Screen | yes | yes | no | no | no |
| Working time | 15 hours | 15 hours | 13 hours | 13-15 hours | 15-18 hours |
| Life Span of the light source | 100000 hours | 100000 hours | 100000 hours | 100000 hours | 100000 hours |
| Battery cycles | 1200 cycles | 1200 cycles | 1200 cycles | 1200 cycles | 1200 cycles |
| Charging time | 4 hours | 4 hours | 4 hours | 4 hours | 4 hours |
| Weight | 200g | 205g | 140g | 140g | 160g |
| Water-proof grade | IP68 | IP68 | IP68 | IP68 | IP68 |
Adjustable light angle:
90 degrees rotation, easy to focus to point as needed without
adjusting your neck.
Application Surroudings:
Suitable for explosive gas environment zone 1, zone 2 locations;
Suitable for combustible dust environment 20 zone, 21 zone and 22
zone places;
Suitable for A, II B, II C explosive gas environment;
Suitable for: indoor, outdoor 1.8-3.5 meters in height;
Application Sites:
*Coal mine lighting&Mining&Visitors mines&Mines rescue
force&UG coal mining
*Tunneling
*Oil ectraction&Chemical engineering
*Expedition&Travel&Camping
*Hunting/outdoor advanture.
*Any place on the dark.
About Green Lighting Electronics CO.,LTD.
We are a professional mining cap lamp factory.
We have a professional design team.
We can produce the mine lamp according to customers' requirement.
Such as shape of the battery box and headlamp, illumination of the
led, capacity of the battery, color of the lamp.
We can design and produce your mining lamp idea.
