Oled Display All In One Cree Led Cap Lamp , Super Bright Coal
Mining Lights With Sos Purpose
1.LED Mining Light specifications
- OLED: Display the battery status, time, date and client's company
information
- Bring you "USE AGAIN"
- Magnetic USB charger or cradles
- Brightness 13000lux
- Three Level: 1 higher, 2 normal, 3 SOS light
Cordless Cap Lamp features a compact, low-fuss click-and-go design,
and offers over20 hours of constant use.
Unique to the cordless model is a back-lit display screen with
battery life indication,
providing clear warning when recharge is required.
2. LED Mining Light Specifications
| Item | Value |
| Light source | 1pcs main light and 2pcs auxiliary lights |
| Battery capacity | 6.2Ah |
| Rated Voltage | 3.7V |
| Main light current | 300mA |
| Power of the main light | 0.96W |
| Illuminous | 125LUM |
| Brightness of the main light | 13000lux |
| Life span for main LED | 100000hours |
| Battery cycles | 1200 cycles |
| Working time | 20 hours |
| 3 Levels Light | Strong light- auxiliary lights- SOS |
| Weight | 200g |
| Water-proof grade | IP68 |
.
3.Usage guide
4.Application
Widely used in petrochemical, chemical, nuclear power, military
automobile shipbuilding industries, suitable for oil pipelines,
cable interlayer, platform channel, pump house , Tunnel Project ,
Mountian-climbing,hiking, Patrolling, Overhauling and Emergency in
electrical power company,Mine , Military, Police, Fire Fighting,
Dockyard and other hazardous locations ect.
5.Troubles and troubleshootings
| Trouble description | Trouble analysis | Troubleshooting |
Light is not on when pressing
the button | Battery power is used up or
Automatic opening protection | Charge the lamp |
Working time is less than
12 hours | Battery is not fully charged | Make sure the lamp well
connected to the charger
when charging |
| Longer charging time | The charging points poor contact | Clean the charging points
and the slot |
| Low illuminance | Dirty lens | Clean water wash lens |
6.Packing:
One set each gift box with 1pc head lamp, 1pc USB charger / Single
Charger and Manual
7.Special Requested
1), May you provide LOGO us to manufacture.
2), High quality and competitive price .
3), Can according to your requested to design new item that
suitable for your market.
4), Above is only for your reference, we can custom make as per
your requested.
5), We sincerely welcome foreign friends who have the need of export.
8.Accept Customized as client's requirements:
Appearance
Strong ID Team, According to client's market positioning, use
condition to design product shape, pattern and colour. Recently,
customized the semi-corded, corded, cordless with Tracking position
and Infrared receiver
Electronic Circuit
Rich Experience Software and Hardware Engineers, PCB's Design and
Layout. LED Driver, Charging circuit, Battery Protection Circuit
and so on.
Write the request to cap lamps, such as clients company name, LOGO,
serie No and user name.
Structural Design
Professional MD Team, provide IP68 Waterproof, ATEX
explosion-proof, Dust-proof Products, 10 years work experience in underground field. Very familiar with miner's lamp industry products. MD team will
field visit and according the use condition to design the
waterproof.
Optical Design
According to LED Luminous Flux, Light cup curve and current to
design the Light Beam
9.FAQ
Q: What does IP mean?
A: IP (Ingress Protection) classifies the degrees of protection
provided against the intrusion of the bulb. The first cipher
indicates the bulbs resistance to solid intruders (like dust), and
the second cipher indicated the bulbs resistance to water
Q:What is the distinguishing feature of explosion proof?
A:Meet GB3836-2000’’explosive gas environment use electrical
equipment’’stand
Q:What is the advantage of environmental protection?
A:The LED solid state light source,no lead and mercury,no radiation
pollution ,after the of recyclable.
Q:What is Lux?
LUX is a measurement of, how much luminous flux is spread over a
given area.
Q: What is Lumen?
Lumen (Lm) is a measure of the total amount power of the light that
is emitted at a 1 meter radius at a 360 degree angle from a light
source.
Integrating Sphere is used to measure Lumen.
Q: How long is 50,000 hours?
There are 8,760 hours in a year, so this is what 50,000 hours works
out to be, depending on hours of operation.
